How to Assess The Durability of Rubbers for Different Applications?

DIN Abrasion tester is widely used in rubber industry to test different forms of rubber, like, natural, synthetic and vulcanized. In this test, the sample is subjected to constant abrasion through a motorised assembly. It has a cylindrical rotating drum that has abrasive surface mounted on it. The sample holder is placed on a vertical axis over the cylinder. The sample is subjected to abrasion when traversed across the drum. The cylinder rotates on its axis, in both vertical and circular direction. Also, the sample holder rotates in its circular axis. This makes the abrasion process very harsh. However, in reality, the conditions are not such this is why this test can be considered as an accelerated test. The samples are subjected to a specific weight as per the industrial standards or testing standards or internal standards of the industry.





• As per the test standards, 1 to and fro of the sample is considered as 1 cycle of the test. Thus, the machine stops automatically when 1 cycle is completed.

• The machine comes with a sample cutting die, so that accurate sample can be prepared according to the testing standards.

• 2 dead weights accompany the machine and they are 5N and 10N.

• The machine follows the testing standard: IS 3400 (Part 3) – 2012: Methods of Test for Vulcanized Rubbers Part 3: Abrasion

• The rotation speed of the cylinder is 40rpm and with each rotation, the sample holder moves 4.2 mm.

• The diameter of the cylinder is 150mm and length of the cylinder is 46mm.

• In one cycle, the cylinder rotates almost 84 times which is approximately 40 meters of travel in a straight path.

If you are looking for precise and standardised DIN Abrasion Tester for your R&D lab or QC lab, contact our experts today and they will help you in choosing the best model at competitive prices.
